DC Output with adjustable constant voltage of 12 or 24 V via DIP Switch
DALI−2 DT6 or Touch DIM dimmable
Linear metal case
Suitable for Class I luminaires
Average lifetime 50.000 h
5 Years warranty
DC Output with adjustable constant voltage of 12 or 24 V via DIP Switch
DALI−2 DT6 or Touch DIM dimmable
Linear metal case
Suitable for Class I luminaires
Average lifetime 50.000 h
5 Years warranty
| Product | Urange | Irated | Prated | Pf | Ripple |
|---|---|---|---|---|---|
| LADV30W24VA | 12 Vdc | 166−2500 mA | 2−30 W | 0.90 C | ± 4 % |
| LADV30W24VA | 24 Vdc | 166−1250 mA | 4−30 W | 0.90 C | ± 3 % |
